Smooth horizontal movement inside the operating areas. Fork Lowering speed is controllable, operated by hand control and foot pedal
| PRODUCT CODE | VI 101 | ||
| CAPACITY | KG | 2500 | 3000 |
| MAX FORK HEIGHT | MM | 200 | 200 |
| MIN FORK HEIGHT | MM | 90 | 90 |
| FORK LENGTH | MM | 1150 | 1220 |
| FORK WIDTH | MM | 550 | 685 |
| LOAD WHEEL SIZE | MM | 80X70 | 80X70 |
| STEERING WHEEL SIZE | MM | 180X50 | 180X50 |
| WHEEL MATERIAL | NYLON/PU | NYLON/PU |
| PRODUCT CODE | VI 102 | |
| CAPACITY | KG | 2/3/5 TON |
| MAX FORK HEIGHT | MM | 200 |
| MIN FORK HEIGHT | MM | 90 |
| FORK LENGTH | MM | AS PER REQ |
| FORK WIDTH | MM | AS PER REQ |
| LOAD WHEEL SIZE | MM | 80X70 |
| STEERING WHEEL SIZE | MM | 180X50 |
| WHEEL MATERIAL | NYLON/PU/METAL |
| PRODUCT CODE | VI 103 | |
| CAPACITY | KG | 2 TO 5 TON |
| MAX FORK HEIGHT | MM | 200 |
| MIN FORK HEIGHT | MM | 90 |
| FORK LENGTH | MM | AS PER REQ |
| FORK WIDTH | MM | AS PER REQ |
| LOAD WHEEL SIZE | MM | 80X70 |
| STEERING WHEEL SIZE | MM | 180X50 |
| WHEEL MATERIAL | NYLON/PU/METAL |
| PRODUCT CODE | VI 104 | |
| CAPACITY | KG | 2 /2.5 TON |
| MAX FORK HEIGHT | MM | 200 |
| MIN FORK HEIGHT | MM | 90 |
| FORK LENGTH | MM | AS PER REQ |
| FORK WIDTH | MM | AS PER REQ |
| LOAD WHEEL SIZE | MM | 80X70 |
| STEERING WHEEL SIZE | MM | 180X50 |
| WHEEL MATERIAL | NYLON/PU | |
| BATTERY | V | DC 1.5V X 4 |
| SELF WEIGHT | KG | 75-125 |
| PRODUCT CODE | VI 105 | |
| CAPACITY | KG | 2 TO 5 TON |
| MAX FORK HEIGHT | MM | AS PER REQ |
| MIN FORK HEIGHT | MM | AS PER REQ |
| FORK LENGTH | MM | AS PER REQ |
| FORK WIDTH | MM | AS PER REQ |
| LOAD WHEEL SIZE | MM | 80X70 |
| STEERING WHEEL SIZE | MM | 180X50 |
| WHEEL MATERIAL | NYLON/PU |
| PRODUCT CODE | VI 106 | |
| CAPACITY | KG | 3 / 5 / 10 |
| MAX FORK HEIGHT | MM | 800 / 1000 |
| MIN FORK HEIGHT | MM | 225 |
| FORK LENGTH | MM | 1580 |
| FORK WIDTH | MM | 680 |
| LOAD WHEEL SIZE | MM | 80X70 |
| STEERING WHEEL SIZE | MM | 180X50 |
| WHEEL MATERIAL | NYLON/PU | |
| SELF WEIGHT | KG | 75-125 |
| PRODUCT CODE | VI 107 | ||
| CAPACITY | KG | 800 | 1000 |
| MAX FORK HEIGHT | MM | 800 | 1000 |
| MIN FORK HEIGHT | MM | 90 | 90 |
| FORK LENGTH | MM | 1150 | 1350 |
| FORK WIDTH | MM | 550 | 650 |
| LOAD WHEEL SIZE | MM | 80X70 | 80X70 |
| STEERING WHEEL SIZE | MM | 180X50 | 180X50 |
| WHEEL MATERIAL | NYLON/PU | NYLON/PU | |
| SELF WEIGHT | KG | 127 | 135 |
Special for the Building Site
| PRODUCT CODE | VI 108 | |
| CAPACITY | KG | 1500 KG |
| HEIGHT | MM | 1298 |
| LIFT HEIGHT | MM | 240 |
| FORK LENGTH | MM | 800 |
| FORK WIDTH | MM | 1605 |
| WHEEL MATERIAL | SCOOTER |
| PRODUCT CODE | VI 109 | |
| DRIVE UNIT | Battery | |
| LOAD CAPACITY | KG | 1500 |
| LOAD CENTER | MM | 600 |
| LOAD DISTANCE | MM | 883/946 |
| WHEELBASE | MM | 1250 |
| SERVICE WEIGHT | KG | 195 |
| TYRE TYPE | Pu | |
| TYRE SIZE, OPERATOR SIDE | MM | 210/70 |
| TYRE SIZE, LOAD SIDDE | MM | 80×60 |
| OVERALL LENGTH | KG | 127 |
| OVERALL WIDTH | MM | 560 |
| FORK LENGTH | MM | 55/150/1150 |
| FORK WIDTH | MM | 560 |
| TURNING RADIUS | MM | <1500/td> |
| LIFTING SPEED | m/s | 0.051/0.060 |
| TRAVEL SPEED | Km/h | 3.5/4 |
| BATTERY VOLATEG/RATED CAPACITY | V/Ah | 24/60 |
| TYPE OF DRIVE | DC |
